MIKROTIK Cat.7 LTE lauko maršrutizatorius SXT LTE7 kit (SXTR&R11e-LTE7)

Product code: SXTR&R11e-LTE7
Architecture: MIPSBE
CPU: QCA9531
CPU core count: 1
CPU nominal frequency: 650 MHz
Switch chip model: QCA9531
RouterOS license: 3
Operating System: RouterOS v7
Size of RAM: 64 MB
Storage size: 16 MB
Storage type: FLASH
MTBF: Approximately 200'000 hours at 25C
Tested ambient temperature: -40°C to 60°C

Powering

Number of DC inputs: 1 (PoE-IN)
Max power consumption: 24 W
Max power consumption without attachments: 7 W
PoE in: 802.3af/at
Cooling type: Passive
PoE in input Voltage: 12-57 V

PoE-out

PoE-out ports: Ether2
PoE out: Passive PoE up to 57V
Low voltage PoE-Out current limit: 600 mA
High voltage PoE-Out current limit: 400 mA
Max total out (A): 600 mA

Mobile

3G Category: R8 (DL: 42.2 Mbps; UL: 5.76 Mbps)
3G bands:
    1 (2100 MHz)
    3 (1800 MHz)
    5 (850 MHz)
    8 (900 MHz)
LTE Category: 7 (DL: 300 Mbps; UL: 100 Mbps)
MIMO DL: 2x2
MIMO UL: 1x1
LTE FDD bands:
    1 (2100 MHz)
    3 (1800 MHz)
    5 (850 MHz)
    7 (2600 MHz)
    8 (900 MHz)
    20 (800 MHz)
    28 (700 MHz)
    32 (1500 MHz)
LTE TDD bands
    38 (2600 MHz)
    40 (2300 MHz)
    41 (2500 MHz)
    TAC 35312597

Ethernet

10/100 Ethernet ports: 2

Peripherals

Number of SIM slots: 2 Modem (Micro SIM)
MiniPCI-e slots: 1

Other

Mode button: Yes

Certification & Approvals

Certification: CE, EAC, ROHS
IP: 54
